STD Work 5

License:

Mode: Editors' pick

  • 216
  • 0
  • 0
Update time: 2021-09-14 16:12:01
Creation time: 2021-09-14 15:09:10
Description

Something

Design Drawing
schematic diagram
1 /
PCB
1 /
The preview image was not generated, please save it again in the editor.
ID Name Designator Footprint Quantity
1 0.1u C1 C0603 1
2 470UF C2 CASE-A_3216 1
3 ZD D1 DO-15 1
4 B80R D2 DIODE_BRIDGE_ROUND_D9.0MM 1
5 Screw Terminal J1,J2 H2-5.0-10.5X8.0MM 2
6 15-21/RSC-BS1T2B/2T LED1 LED1206-RD-R_RED 1
7 470K R1 R0603 1
8 100 R2 R0603 1
9 1k R3 R0603 1
10 220 R4 R0603 1

Unfold
