STD 2596 sep-18
Project Status:
Ongoing
- 0
Description
Empty
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
-
NEW_PCB
Open in Editor -
2596 baquela
Open in Editor -
2596 baq2
Open in Editor -
NEW_PCB22
Open in Editor -
NEW_PCB 2019
Open in Editor
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Footprint | Quantity |
|---|---|---|---|---|
| 1 | C1 | C1 | CAPACITOR 3300MF50V | 1 |
| 2 | Сapacitor_3300uF50v | C2 | CAPACITOR 3300MF50V | 1 |
| 3 | 0.22uf | C3,C4,C31 | RAD-0.1 | 3 |
| 4 | 1N5822 | D1,D2,D3 | DO-201AD | 3 |
| 5 | verde | D4 | LED-3MM/2.54 | 1 |
| 6 | Bobina | L1 | BOBINA TOROIDE 9MM X 24MM | 1 |
| 7 | rojo | LED1 | LED-3MM/2.54 | 1 |
| 8 | v-in | P3 | CONECTOR MACHO 5.1MM X 2 | 1 |
| 9 | v-aut | P4 | CONECTOR MACHO 5.1MM X 2 | 1 |
| 10 | BC548 | Q1 | TO92 | 1 |
| 11 | 10k | R1 | AXIAL-0.4 | 1 |
| 12 | 390 | R2,R4 | AXIAL-0.4 | 2 |
| 13 | 2.2k | R3 | AXIAL-0.4 | 1 |
| 14 | 1k | R5 | AXIAL-0.8 | 1 |
| 15 | 390 | R6 | AXIAL-0.3 | 1 |
| 16 | 470 | R7 | AXIAL-0.4 | 1 |
| 17 | 1k | R8 | AXIAL-0.3 | 1 |
| 18 | 10k | RV1,RV4 | RES-ADJ_3386P | 2 |
| 19 | 1k | RV2,RV3 | RES-ADJ_3386P | 2 |
| 20 | LM7805L | U | TO-220(TO-220-3) | 1 |
| 21 | LM2596T-12 | U4 | T05D | 1 |
| 22 | LM358 | U2 | DIP08 | 1 |
