STD FONTE COM AJUSTE DE TENSÃO VARIÁVEL
Profile：Fonte com ajuste de tensão variável
License: Public Domain
Description
Fonte com ajuste de tensão variável
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
Empty
| ID | Name | Designator | Quantity |
|---|---|---|---|
| 1 | 2200u | C1 | 1 |
| 2 | 1000u | C2 | 1 |
| 3 | 1N4148 | D1,D2,D3,D4 | 4 |
| 4 | 220 | R1 | 1 |
| 5 | 10K | R2 | 1 |
| 6 | 4.7K | RP1 | 1 |
| 7 | 0.05 | T2 | 1 |
| 8 | LM317EE | U1 | 1 |
| 9 | SIN(0 311.1269 60 10m 0 0) | VAC | 1 |
| 10 | Multimeter | XMM1 | 1 |
| 11 | Oscilloscope | XSC1 | 1 |
