STD Pic Temperature controller
Mode: Editors' pick
- 1
Update time：
2022-01-02 15:56:15
Creation time：
2018-11-19 08:02:31
Description
Empty
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Footprint | Quantity | Mounted | |
|---|---|---|---|---|---|---|
| 1 | PIC16F877A-IP | U1 | DIP40 | 1 | Yes | |
| 2 | LM35DZ | U2 | TO-92 | 1 | Yes | |
| 3 | -L7805 | U3 | L7805 | 1 | Yes | |
| 4 | Diode_Bridge | D1 | DIODE BRIDGE W10M | 1 | Yes | |
| 5 | CON_2 | U4 | CON_2_SCREW | 1 | Yes | |
| 6 | 1000uF-25V | C1 | RAD-315 | 1 | Yes | |
| 7 | 0.1uF-50V | C2 | CAP-PTH-SMALL-KIT | 1 | Yes | |
| 8 | 27pF | C3,C4 | CAP200 | 2 | Yes | .09 |
| 9 | 0.1UF-50V | C5,C6 | CAP-PTH-SMALL-KIT | 2 | Yes | |
| 10 | 1k | R1 | RC07 | 1 | Yes | |
| 11 | 1KOHM-1_4W | R2 | AXIAL-0.3 | 1 | Yes | |
| 12 | 0.1UF-50V-20% | C8 | CAP-PTH-SMALL-KIT | 1 | Yes | |
| 13 | LCD-DMC1602B | U5 | DMC1602B | 1 | Yes | |
| 14 | 220 | R3 | AXIAL-0.3 | 1 | Yes | |
| 15 | 1K | R4,R6 | AXIAL-0.3 | 2 | Yes | |
| 16 | void | Q1 | TO-92 | 1 | Yes | |
| 17 | RELAY_RELAY-JZC | U6 | RELAY_JS-M | 1 | Yes | |
| 18 | Diode 1N4007 | D2 | DIODE 0.4 | 1 | Yes | |
| 19 | 4.7K | R5 | AXIAL-0.3 | 1 | Yes | |
| 20 | LED | LED1 | LED3MM | 1 | Yes | |
| 21 | CON_3 | U7 | TERMINAL_BLOCK_3P_5 | 1 | Yes | |
| 22 | POT | RV1 | POT93YA | 1 | Yes | |
| 23 | 0.1uF | C7 | CAP-PTH-SMALL-KIT | 1 | Yes | |
| 24 | 1KOHM-1_4W-5%(PTH) | R7 | AXIAL-0.3 | 1 | Yes | |
| 25 | POWER LED | LED2 | LED3MM | 1 | Yes | |
| 26 | 20MHz | Y1 | HC49US | 1 | Yes |
