STD FSG_2019_BSPD_0.3.sch
Mode: Editors' pick
- 0
Update time：
2021-10-28 21:43:44
Creation time：
2019-01-30 17:55:27
Description
Empty
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Quantity |
|---|---|---|---|
| 1 | 100n | C101,C102,C105,C107,C109,C110 | 6 |
| 2 | 10µ | C103,C106,C108 | 3 |
| 3 | 10µ | C104 | 1 |
| 4 | DF2B36FU | D101,D102,D104 | 3 |
| 5 | MCL4148 | D103 | 1 |
| 6 | A4L-LOC | FRAME1 | 1 |
| 7 | LM393AD | I101,I102,I103 | 3 |
| 8 | SN74AHC1G02DBVR | I104 | 1 |
| 9 | LM1117MPX-5.0 | I105 | 1 |
| 10 | 20k | R101,R115 | 2 |
| 11 | 100k | R102,R113,R116,R123,R124 | 5 |
| 12 | 10k | R103,R106,R107,R108,R111,R112,R114,R117,R118,R120,R121 | 11 |
| 13 | 39k | R104,R105,R109 | 3 |
| 14 | 100R | R110,R122 | 2 |
| 15 | 560k | R119,R125 | 2 |
| 16 | Si2309CDS | T101 | 1 |
| 17 | BSS138 | T102,T103 | 2 |
| 18 | PINHD-1X6 | X101 | 1 |
| 19 | CP1-12V | K101 | 1 |
