STD rfid door lock
Mode: Editors' pick
- 0
Update time：
2018-09-16 22:53:38
Creation time：
2018-09-07 16:53:58
Description
Empty
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Footprint | Quantity | Mounted | |
|---|---|---|---|---|---|---|
| 1 | RFID | U1 | EM-18 | 1 | Yes | OEM181AM-608S-ND |
| 2 | LCD-16X2NOHOLES | U2 | LCD-16X2_NOHOLES | 1 | Yes | |
| 3 | 10k | R1 | RES-ADJ_3386P | 1 | Yes | C125022 |
| 4 | 10k | R2 | AXIAL-0.3 | 1 | Yes | |
| 5 | ATMEGA16A-PU | U3 | DIP-40 | 1 | Yes | C30504 |
| 6 | DC motor | U5 | DIP | 1 | Yes | |
| 7 | L293D | U6 | DIP-16 | 1 | Yes | C12340 |
| 8 | 100uF | C4,C6 | RAD-0.2 | 2 | Yes | |
| 9 | 220uF | C5,C7 | RAD-0.2 | 2 | Yes | |
| 10 | XTAL | 11.0592MHZ | OSC-49S-1 | 1 | Yes | C16369 |
| 11 | 22pF | C1,C2 | RAD-0.2 | 2 | Yes | |
| 12 | 10uF | C3 | RAD-0.2 | 1 | Yes | |
| 13 | sw | SW1 | KEY-6.0*6.0-4 | 1 | Yes | C79156 |
| 14 | LM7805 | U4 | TO39 | 1 | Yes | |
| 15 | 0.22uF | C8 | RAD-0.2 | 1 | Yes | |
| 16 | 220 | R3 | AXIAL-0.3 | 1 | Yes | |
| 17 | 4 | SW2 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 18 | 5 | SW3 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 19 | 6 | SW4 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 20 | 9 | SW5 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 21 | 8 | SW6 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 22 | 7 | SW7 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 23 | * | SW8 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 24 | 0 | SW9 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 25 | # | SW10 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 26 | D | SW11 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 27 | C | SW12 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 28 | B | SW13 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 29 | 1 | SW14 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 30 | 2 | SW15 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 31 | 3 | SW16 | SMD-6.1X3.6 | 1 | Yes | C118141 |
| 32 | A | SW17 | SMD-6.1X3.6 | 1 | Yes | C118141 |
