Design Drawing
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Footprint | Quantity |
|---|---|---|---|---|
| 1 | 680 | R1,R2 | AXIAL-0.3 | 2 |
| 2 | 1k | R3,R4 | AXIAL-0.3 | 2 |
| 3 | LED-3MM | LED1,LED2,LED3 | LED-3MM/2.54 | 3 |
| 4 | led-3 | LED4 | LED-3MM/2.54 | 1 |
| 5 | RX/EX/MX-Series (RS-485 Version) | U1 | JST_SH_BM04B-SRSS-TB_04X1.00MM_STRAIGHT | 1 |
| 6 | BM04B-SRSS-TB(LF)(SN) | U2,RX/EX/MX-SERIES (RS-485 VERSION),X-SERIES (RS-485 VERSION) | JST_SH_BM04B-SRSS-TB_04X1.00MM_STRAIGHT | 3 |
