STD placa ir2110
placa ir2110
License
License:Mode:
Mode
Editors' pickEditors' pick
- 0
Update time：
2019-05-27 18:49:19
Creation time：
2018-12-24 19:15:30
Description
Description
Empty
Design Drawing
Design Drawing
schematic diagram
（
1
/
）
PCB
（
1
/
）
The preview image was not generated, please save it again in the
editor.
| ID | Name | Designator | Footprint | Quantity |
|---|---|---|---|---|
| 1 | AMC1100DUB | U7 | DIP8-GULLWING | 1 |
| 2 | 12 | R4,R5,R7,R8,R9 | AXIAL-0.3 | 5 |
| 3 | 330p | C14 | RAD-0.2 | 1 |
| 4 | 0.1u | C16,C17 | RAD-0.2 | 2 |
| 5 | 100k | R6 | AXIAL-0.4 | 1 |
| 6 | 1N4148 | D9,D1,D2,D3,D4,D5,D6 | DO-35 | 7 |
| 7 | ZTK | D10 | DO35Z10 | 1 |
| 8 | IR2110STRPBF | U1,U2,U3 | SOIC-16_300MIL | 3 |
| 9 | 470nf | C2,C3,C5 | CAP-3.5*9*7 | 3 |
| 10 | 4.7uF | C1,C4,C6,C7 | CAP-D5.0XF2.0 | 4 |
| 11 | Header-Male-2.54_1x3 | P4,P1,P2,P5,P6,P9 | HDR-3X1/2.54 | 6 |
| 12 | Header-Male-2.54_1x2 | H1,H2,H3 | HDR-2X1/2.54 | 3 |
| 13 | 1uF | C8,C11,C12 | 1206 | 3 |
| 14 | IR2136STRPBF | U5 | SOIC-28_300MIL | 1 |
| 15 | 0.1u | C9 | 1206 | 1 |
| 16 | INPUT | P8 | HDR-IDC-2.54-2X5P | 1 |
| 17 | OUT | P7 | HDR-IDC-2.54-2X6P | 1 |
| 18 | DOIT ESP32 Devkit V1 IF | U6 | DOIT ESP32 DEVKIT V1 | 1 |
| 19 | Header-Female-2.54_1x2 | P3 | HDR-1X2/2.54 | 1 |
| 20 | Header-Male-2.54_1x4 | H5 | DIP-1X4P-2.54MM-M | 1 |
| 21 | Header-Male-2.54_1x1 | P10 | HDR-1X1/2.54 | 1 |
