Description
A Breakout PCD for ESP-07S with Wemos Mini pinout. AMS1117 voltage regulator. pullups and pulldown R.
ESP-07S
R1, 2, 3 = 0805 3k3
R4 = 0805 470R
C1, C2 = 0805 10µF
LED = 0805 blue
AMS1117 3.3 V
pin header 2x 7
